Bay Pro 220 Elite
									      New release March 2023

Meet our newest bay boat, the 220 Elite, our widest front deck 22' model with a new hull design, Elite stylish rigging, impressive floor layout, increased speed and an improved ride. One sweet package...

SPECS
| Length | 22' 3" |
| Overall Length with Engine | 24' 5" |
| Overall Length with Engine and Trailer | 26' 5" |
| Bottom Width | 68" |
| Side Height | 25" |
| Transom Height | 21" |
| Transom Deadrise | 14 degree |
| Beam Width | 94" |
| Front Deck Beam Width | 70" (7.5" more than our standard Bay Pro 220) |
| Fuel Capacity | 30 gallon |
| Console Livewell | 16 gallon |
| Aft Livewell | 27 gallon |
| Forward Deck Step Fish Box/Cooler | 45 quart |
| Max Horsepower | 200 HP |
| Capacity Person/Lbs | 8/1157 |
| Persons, Gear, Motor | 2020 lbs |
| Hull Thickness | 0.160 (thickest in the boating industry) |
- All-welded 14 degree Pad Hull with Lifting Strakes
- Bow - Twin Built-in Tackle Boxes - Port and Starboard
- Bow - Dry Storage Center - 6 Cubic Feet
- Bow - Integrated Trolling Motor Bracket
- Bow - 24-36 Volt Plug
- Bow - 12V Electronics (fish finder/GPS) Pre-Wire (stubbed out)
- Bow - Engine Trim Switch
- Bow - Navigation Light Switch
- Four Cup Holders

- Rear Storage Trays with 12V and USB Plugs - Port and Starboard
- Full Gauge Set (Speed, Tach and Fuel)
- Multi Button Switch Panel with 12V Plug and phone USB
- Font Deck Step with 45 Quart Fish Box/Insulated Ice Chest
- Console Six Rod Holders
- Built-in-Dash Mount for the 5, 7, 9 or 12" Lowrance or Humminbird Electronics
- Lockable Under Dash Storage
- Deluxe Lean Post with Step, Rod Holders, and Cooler Mount
- Transom 45 Degree Splash Well
- Twin Deluxe Rear Deck Jump Seats with Storage
- Extruded Gunwale (w/rubber rub rail w/accessory mounting slot)
- 30 Gallon Fuel Tank
- 20 Gallon Livewell Rear Deck
- 16 Gallon Console Livewell
- Dual Auto Bilge 1100 GPH
- Four Mooring Cleats
- All Gloss Paint Colors Standard
- Superliner Durable Deck and Gunwale Coating
- Twin Transom Raised 5" Wide Transducer Mounting Brackets
- Bow Seat with Pole
- New high-quality premium seats
- Elite includes 2 tempress fold-down seats, console back, console bottom, leaning post bottom
- New steering wheel with Excel branded center cap (same as bass boat)
- standard polished 13.5" Verona steering wheel from Syntec
- Elite decals added to console
- New Excel decals hull package
- Matte black decals (all decals) for phantom package and also for camo boats
- Elite model has 2 accent lights added in rear storage rigging compartment (white)
- Elite bay pro has increased foredeck width at aft edge of about 9", rod boxes also are now 3-4" wider
- New gunwale shear line appearance
- New bow cap appearance
- New high quality premium seats
 - leaning post backrest
 - rod box cushions x 2
 - quantum seats

- Upgradeable steering wheels
 - Verona black 13.5" verona steering wheel from syntec
- Reflex flooring
 - Plus 18mm Anti-fatigue helm pad is also another upgrade
- Elite LED package
 - New RGB-W 1" round lights and underwater lights replaced current lights
 Colors (white, purple, red. green, blue)
 - remote controlled gunwale led strips full length, silicone encased, marine grade, etc.
 - 1 additional accent light added in each rod box (2 total)
- 2 or 3 Bank Battery Charger
- Battery Disconnect Switch
- Tilt Helm
- Engine Water Pressure Gauge
- Analogue Voltage Gauge
- SeaDek Deck Covering
- Interior LED Lighting
- 3-step Ladder
- 26 Quart Orca Cooler (fits under lean post)
- Reflex Helm Pad
- Rod Box Cushions
- Recirculating Baitwell & Livewell
- Lean Post Backrest and 3 Rod Holders
- Stainless Steel Package (Gauges, Recessed Mooring Cleats, Cup Holders)
- 3" Bluetooth Radio w/2 Speakers
- Full Line of Minn Kota Trolling Motors
- Humminbird or Lowrance in Dash 5, 7, or 9"
- Power Pole(s) 10'
- Storage Cover
- 6" Atlas Jack Plate Hydraulic
- 6” Jack Plate Manual
- Yamaha Outboards
- Mercury Outboards
- Suzuki Outboards
- Honda Outboards
- Boat Seat w/Pole
- Black/Gray, Cafe, Putty and Cafe/Putty Upholstery
